| Mounted Systems | RAM Self-Compensating Dripper | 16 mm or 17 mm Tube |  | Technical features
Space between drippers (m) | 0,50 | 0,75 | 1,00 |
Working pressure 0,5kg/cm2 to 4.0kg/cm2 | | Flow(l/h) | 2,3 | 3,5 |
| | | | | Techline - NETAFIM Self-Compensating (brown Tube) | 16 mm Tube |
| Technical features
Space between drippers (m) | 0,33 | 0,50 |
Working pressure 0,5kg/cm2 to 4.0kg/cm2 | | Flow(l/h) | 2,3 | 3,5 |
| | Rolls: 100 m | | | Katif Self-Compensating | 16 mm Tube |  | Technical features
Space between drippers (m) | 0,33 | 0,50 | 0,75 | 1,00 |
Working pressure 0,6kg/cm2 to 4.0kg/cm2 | | Type(cor) | Black | Red | Green | | Flow(l/h) | 2,3 | 3,8 | 8,4 |
|
| Rolls: 100 and 200 m ( for special measures, please contact us) | Interline Mace turbulent dripper | 16 mm Tube |  | Technical features
Space between drippers (m) | 0,33 | 0,50 | 0,75 | 1,00 |
| Pressure (kg/cm2) | 0,5 | 1 | 1,5 | 2 | 2,5 | | Flow (l/h) | 3.1 | 4.7 | 5.9 | 6.9 | 8.0 |
|
| Rolls: 100 and 200 m ( for special measures, please contact us) | | Flow Regulating Dripper (Brown Tube or Black Tube) | | 16 mm tube |  | Technical Features Space between drippers (m) | 0,30 | 0,50 | 1,00 |
| | | Pressure (kg/cm2) | 0,5 | 1,0 | 1,5 | 2,0 | | Flow (l/h) | 2,5 | 3,4 | 4,5 | 5,4 |
| | | Coils: 100 m | Poly-tube (16 mm diameter) with dripper - Streamline - NETAFIM |  | Technical features
Space between drippers (m) | 0,20 |
Max Pressure 0,85 kg/cm2 | | Flow(l/h) | 1,0 |
| | | Rolls: 200 m and 2200 m | | | |
| Adjustable flood dripper
| Flow at 1 (kg / cm2) | 0 - 55 l/h |
| | | | | Adjustable flood dripper with support
| Flow at 1 (kg / cm2) | 0 - 33 l/h |
| | | Endleess type adjustable PG dripper
| Flow at 1 (kg / cm2) | 0 - 6 l/h |
| | | Endleess type adjustable plc dripper
| Flow at 1 (kg / cm2) | 4 - 30 l/h |
| | | Removable Self-Compensating
| Flow from 1 to 5 (kg / cm2) | 2.0 l/h | 4.0 l/h |
| | | *Self-Compensating Katif
| Flow from 0,6 to 4 (kg / cm2) | | black 2.3 l/h | | red 3.8 l/h | | green 8.4 l/h |
*It can be supplyed inserted in the 16 mm tube in intervals from 0.33 to 1 m
| | | Self-Compensating PCJ Netafim
| Flow from 0,5 to 4 (kg / cm2) | | red 2 l/h | | grey 4 l/h | | green 8 l/h |
| | | Removable O-TIFf dripper
Flow at 1 (kg / cm2) | 8.0 l/h |
| |
| Removable Nein dripper
Flow at 1 (kg / cm2) | 8.0 l/h |
| | | Stake Dripper
Flow at 1 (kg / cm2) | 2.3 l/h |
| | | micro-tube Stake
Flow at 1 (kg / cm2) | 25 l/h |
| |
| *Mace dripper
Flow at 1 (kg / cm2) | 4.7 l/h |
*It can be supplyed inserted in the 16 mm tube in intervals from 0.33 to 1 m
| |
| Removable mace dripper
Flow at 1 (kg / cm2) | 3,8 l/h | 8 l/h |
| |
|
|
